Say Goodbye To The Diesel Generator
Be one of first to try the world’s first towable welfare unit with no on-board generator at all. We are proud to offer this brand-new 100% silent running, virtually zero emission welfare solution to our most eco-conscious clients.
Advanced solar harvesting technology draws power from an extensive extendable array of high-capacity panels on the roof and sides of the cabin, with energy stored in lithium ion batteries. Even in the depths of winter, sufficient energy is generated to power all the functions of a hard-working welfare cabin.
With no diesel-hungry generator needed to power any electrical operation and just 0.25 litres of fuel used per hour in the low-consumption heater, this cabin offers huge savings both financially and in terms of CO2 emissions. Zero emissions in summer months when no heater is required and a bare minimum in winter, making them suitable for emission-restricted areas.
As in all our towable EcoPro cabins, patented rain harvesting and water recycling technology reduces the amount of waste pump outs and water deliveries required, saving yet more cash and time on service visits.
EcoPro Solar Welfare cabins cater for 7 up to 15 people with twin female and male toilets.
Our Solar Welfare Range
Electrical Spec
- Electrics powered 100% by solar – solar panels on roof, walls and extendable tray produce clean free renewable energy
- All electrical items run from battery power alone – lights, USB chargers, 500W 230V low-power inverted 3-pin sockets
- Solar energy stored in 1 x 512 kWh lithium-ion batteries
- Ultra-low consumption diesel heater uses only 0.25 litres of fuel p/hour with minimal emissions
- Heater is HVO biofuel-compatible. Use HVO to lower CO2 by further 90%. Swap between HVO and diesel seamlessly
- No on-board generator means 100% silent operation at all times
- Easy to operate – one switch power-on-demand function
- Remote 24/7 online monitoring of solar energy production and usage plus heater fuel consumption, tank levels and faults
- PIR sensor interior LED lighting. Exterior lights PIR-sensor and dusk-to-dawn sensor activated
Sizing Spec
| Attribute | Measurement |
|---|---|
| Unit Length | 3650mm |
| Unit Width | 2300mm |
| Unit Height | 2630mm |
| Towing Length | 4775mm |
| Towing Height | 2900mm |
| Net Weight | 2211kg |
| Fuel Tank | 50 litres |
Electrical Spec
- Electrics powered 100% by solar – solar panels on roof, walls and extendable tray produce clean free renewable energy
- All electrical items run from battery power alone – lights, USB chargers, 500W 230V low-power inverted 3-pin sockets, kettle, microwave, hand dryers and electric hydraulic deployment
- Solar energy stored in 2 x 512 kWh lithium ion batteries
- Heating provided by ultra-low consumption heater using 0.25 litres fuel per hour. Runs on white diesel or HVO biofuel with 90% reduced net CO2 emissions
- Zero emission operation in summer months. Heater creates minimal emissions in winter months
- No on-board generator means 100% silent operation at all times
- Easy to operate – one switch power-on-demand function
- Remote 24/7 online monitoring of solar energy production and usage plus heater fuel consumption, tank levels and faults
- PIR sensor interior LED lighting. Exterior lights PIR-sensor and dusk-to-dawn sensor activated.
Sizing Spec
| Attribute | Measurement |
|---|---|
| Unit Length | 3650mm |
| Unit Width | 2300mm |
| Unit Height | 2630mm |
| Towing Length | 4775mm |
| Towing Height | 2900mm |
| Internal Height | 1990mm |
| Internal Width | 2130mm |
| Net Weight | 2211kg |
| Fresh Water Tank | 140 litres |
| Waste Tank | 230 litres |
| Fuel Tank | 56 litres |
Electrical Spec
- Electrics powered 100% by solar – solar panels on roof, walls and extendable tray produce clean free renewable energy
- All electrical items run from battery power alone – lights, USB chargers, 500W 230V low-power inverted 3-pin sockets
- Solar energy stored in 1 x 512 kWh lithium-ion batteries
- No on-board generator means 100% silent operation at all times
- Easy to operate – one switch power-on-demand function
- Remote 24/7 online monitoring of solar energy production and usage plus heater fuel consumption, tank levels and faults
- PIR sensor interior LED lighting. Exterior lights PIR-sensor and dusk-to-dawn sensor activated.
Sizing Spec
| Attribute | Measurement |
|---|---|
| Unit Length | 3370mm |
| Unit Width | 2600mm |
| Unit Height | 2570mm |
| Weight | 2600kg |
| Total Waste Tank | 958 litres |
| Grey Water Tank | 30 litres |
| Fresh Water Tank | 500 litres |
| Cubicle Internal Length | 1200mm |
| Cubicle Internal Width | 1170mm |
| Cubicle Internal Height | 2000mm |
Electrical Spec
- Electrics powered 100% by solar – solar panels on roof, walls and extendable tray produce clean free renewable energy
- All electrical items run from battery power alone – lights, USB chargers, 500W 230V low-power inverted 3-pin sockets, kettle, microwave, hand dryers and electric hydraulic deployment
- Solar energy stored in 2 x 512 kWh lithium ion batteries
- Heating provided by ultra-low consumption heater using 0.25 litres fuel per hour. Runs on white diesel or HVO biofuel with 90% reduced net CO2 emissions
- Zero emission operation in summer months. Heater creates minimal emissions in winter months
- No on-board generator means 100% silent operation at all times
- Easy to operate – one switch power-on-demand function
- Remote 24/7 online monitoring of solar energy production and usage plus heater fuel consumption, tank levels and faults
- PIR sensor interior LED lighting. Exterior lights PIR-sensor and dusk-to-dawn sensor activated.
Sizing Spec
| Attribute | Measurement |
|---|---|
| Unit Length | 3650mm |
| Unit Width | 2300mm |
| Unit Height | 2630mm |
| Towing Length | 4775mm |
| Towing Height | 2900mm |
| Internal Height | 1990mm |
| Internal Width | 2130mm |
| Net Weight | 2211kg |
| Fresh Water Tank | 140 litres |
| Waste Tank | 230 litres |
| Fuel Tank | 56 litres |
Electrical Spec
- Electrics powered 100% by solar – solar panels on roof, walls and extendable tray produce clean free renewable energy
- All electrical items run from battery power alone – lights, USB chargers, 500W 230V low-power inverted 3-pin sockets, kettle, microwave, hand dryers and electric hydraulic deployment
- Solar energy stored in 2 x 512 kWh lithium ion batteries
- Heating provided by ultra-low consumption heater using 0.25 litres fuel per hour. Runs on white diesel or HVO biofuel with 90% reduced net CO2 emissions
- Zero emission operation in summer months. Heater creates minimal emissions in winter months
- No on-board generator means 100% silent operation at all times
- Easy to operate – one switch power-on-demand function
- Remote 24/7 online monitoring of solar energy production and usage plus heater fuel consumption, tank levels and faults
- PIR sensor interior LED lighting. Exterior lights PIR-sensor and dusk-to-dawn sensor activated.
Sizing Spec
| Attribute | Measurement |
|---|---|
| Unit Length | 4846mm |
| Unit Width | 2300mm |
| Unit Height | 2630mm |
| Towing Length | 5988mm |
| Towing Height | 2900mm |
| Internal Height | 1990mm |
| Internal Width | 2130mm |
| Net Weight | 2420kg |
| Fuel Tank | 56L |
| Fresh Water Tank | 160L |
| Waste Canteen | 25L |
| Toilet Waste Tank | 229L |
| Drinking Water | 20L |
Electrical Spec
- Electrics powered 100% by solar – solar panels on roof, walls and extendable tray produce clean free renewable energy
- All electrical items run from battery power alone – lights, USB chargers, 500W 230V low-power inverted 3-pin sockets, kettle, microwave, hand dryers and electric hydraulic deployment
- Solar energy stored in 2 x 512 kWh lithium ion batteries
- Heating provided by ultra-low consumption heater using 0.25 litres fuel per hour. Runs on white diesel or HVO biofuel with 90% reduced net CO2 emissions
- Zero emission operation in summer months. Heater creates minimal emissions in winter months
- No on-board generator means 100% silent operation at all times
- Easy to operate – one switch power-on-demand function
- Remote 24/7 online monitoring of solar energy production and usage plus heater fuel consumption, tank levels and faults
- PIR sensor interior LED lighting. Exterior lights PIR-sensor and dusk-to-dawn sensor activated.
Sizing Spec
| Attribute | Measurement |
|---|---|
| Unit Length | 4846mm |
| Unit Width | 2300mm |
| Unit Height | 2630mm |
| Towing Length | 5988mm |
| Towing Height | 2900mm |
| Internal Height | 1990mm |
| Internal Width | 2130mm |
| Net Weight | 2420kg |
| Fuel Tank | 56L |
| Fresh Water Tank | 160L |
| Waste Canteen | 25L |
| Toilet Waste Tank | 229L |
| Drinking Water | 20L |
Electrical Spec
- Electrics powered 100% by solar – solar panels on roof, walls and extendable tray produce clean free renewable energy
- All electrical items run from battery power alone – lights, USB chargers, 500W 230V low-power inverted 3-pin sockets, kettle, microwave, hand dryers and electric hydraulic deployment
- Solar energy stored in 2 x 512 kWh lithium ion batteries
- Heating provided by ultra-low consumption heater using 0.25 litres fuel per hour. Runs on white diesel or HVO biofuel with 90% reduced net CO2 emissions
- Zero emission operation in summer months. Heater creates minimal emissions in winter months
- No on-board generator means 100% silent operation at all times
- Easy to operate – one switch power-on-demand function
- Remote 24/7 online monitoring of solar energy production and usage plus heater fuel consumption, tank levels and faults
- PIR sensor interior LED lighting. Exterior lights PIR-sensor and dusk-to-dawn sensor activated.
Sizing Spec
| Attribute | Measurement |
|---|---|
| Unit Length | 6988mm |
| Unit Width | 2300mm |
| Unit Height | 2480mm |
| Towing Length | 8364mm |
| Towing Height | 2860mm |
| Internal Height | 1990mm |
| Internal Width | 2130mm |
| Net Weight | 3048kg |
| Toilet Freshwater Tank | 250 litres |
| Waste Tank | 340 litres |
| Fresh Water Tank | 200 litres |
| Fuel Tank | 28 litres |
Electrical Spec
- Electrics powered 100% by solar – solar panels on roof, walls and extendable tray produce clean free renewable energy
- All electrical items run from battery power alone – lights, USB chargers, 500W 230V low-power inverted 3-pin sockets, kettle, microwave, hand dryers and electric hydraulic deployment
- Solar energy stored in 2 x 512 kWh lithium ion batteries
- Heating provided by ultra-low consumption heater using 0.25 litres fuel per hour. Runs on white diesel or HVO biofuel with 90% reduced net CO2 emissions
- Zero emission operation in summer months. Heater creates minimal emissions in winter months
- No on-board generator means 100% silent operation at all times
- Easy to operate – one switch power-on-demand function
- Remote 24/7 online monitoring of solar energy production and usage plus heater fuel consumption, tank levels and faults
- PIR sensor interior LED lighting. Exterior lights PIR-sensor and dusk-to-dawn sensor activated.
Sizing Spec
| Attribute | Measurement |
|---|---|
| Unit Length | 6988mm |
| Unit Width | 2300mm |
| Unit Height | 2480mm |
| Towing Length | 8364mm |
| Towing Height | 2860mm |
| Internal Height | 1990mm |
| Internal Width | 2130mm |
| Net Weight | 3048kg |
| Toilet Freshwater Tank | 250 litres |
| Waste Tank | 340 litres |
| Fresh Water Tank | 200 litres |
| Fuel Tank | 54 litres |
